G SeriesConvenient Detectors
Cutting-edge laser technology for precise gas detection with automatic calibration and smart connectivity
Accuracy
±1 ppm
Response Time
< 1 second
Lifespan
10+ years
Certification
Approved
Product Gallery
Click any image to view details
G20 Telescopic Probe
Telescopic Probe Long
G10E Ethane Identifier With Standard Probe
Telescopic Probe Short
See G-Series in Action
G10 Telescopic Probe
G10 & G10E Ethane and Methane Leak Detector
Field Inspection (A20+G10E)
Technical Specifications
Download Full Brochure (PDF)G10
Measuring Principle
Tunable Diode Laser Absorption
Static Detection Limit
1 ppm
Response Time
< 1 second
Concentration Range
0 ~ 500 ppm
Operating Temperature
-10 ~ 50°C
Main Unit Dimension
220 × 90 × 70 mm
Main Unit Weight
550 g
Detection Subject
Methane (CH₄)
G10V
Measuring Principle
Tunable Diode Laser Absorption
Static Detection Limit
0.5 ppm
Response Time
< 1 second
Concentration Range
0 ~ 500 ppm
Operating Temperature
-10 ~ 50°C
Main Unit Dimension
220 × 90 × 70 mm
Main Unit Weight
550 g
Detection Subject
Methane (CH₄)
G10E
Measuring Principle
Tunable Diode Laser Absorption
Static Detection Limit
2 ppm
Response Time
< 1 second
Concentration Range
0 ~ 500 ppm
Operating Temperature
-10 ~ 50°C
Main Unit Dimension
220 × 90 × 70 mm
Main Unit Weight
550 g
Detection Subject
Ethane (C₂H₆)
Complete Product Line
Discover our G-Series detector family, each designed to meet specific gas detection needs
G10
Portable Laser Gas Detector
High-precision portable detector with advanced laser technology
G10V
Vehicle Inspection System
Integrated system for electric vehicles with rangefinder
G10E
Laser Ethane Detector
Specialized in precise ethane detection with real-time analysis
Why Choose G Series?
Revolutionary technology that surpasses traditional detection methods
Advanced Laser Technology
Superior performance to traditional equipment with longer lifespan
Automatic Calibration
Integrated gas reference for continuous auto-calibration
Ergonomic Design
Optimized rod for fast and precise detection on roads
Smart Connectivity
AlphaOne app with Bluetooth and network connectivity
Comparison with Traditional Technologies
See how our laser technology surpasses conventional methods
| Feature | Traditional Methods | G Series (Laser) |
|---|---|---|
| Analysis Time | Several minutes | Real time (< 1s) |
| Measurement Type | Qualitative | Precise quantitative |
| Result | Complex graphs | Direct concentration value |
| Lifespan | 3 years (key parts) | 10+ years |
| Maintenance | Frequent | Minimal |
Advanced Features
- • Integrated GPS for mapping
- • Cloud storage
- • Real-time data analysis
- • Customizable alerts
Ready to Revolutionize Your Gas Detection?
Contact us for a personalized demonstration of G Series products and discover how our technology can transform your operations.
